LaundryChipTM 401
FT-401-ST / FT-401-PA / FT-401-Pouch.
The best reading performance ever and endurance in the harshest environments in a small size, for a no-wear feeling and unnoticeable look! Visit the dedicated web page.
Successfully certified as OEKO-TEX® Standard 100 (Discover more) and MR (Magnetic Resonance) conditional (Discover more).
Available in 3 versions: Source Tagging (to be sewn), Patchable and in Pouch.

LaundryChipTM 403
FT403
The FT403 is the smallest LaundryChipTM ever and it’s perfect for those applications that can cope with shorter reading distances but where the transponder is required to be absolutely undetectable (e.g. private wear).Visit the dedicated web page.
Successfully certified as OEKO-TEX® Standard 100 (Discover more), it’s available in a single version ST/PA.

LaundryChip™ 401 in Roll
FT401 in roll.
This “in-roll” LaundryChip™ configuration allows automatic insertion of our FT401-ST directly during the automatic linen manufacturing process. Discover more.

LaundryChip™ 40I PA with 2D CODE
FT40I-PA QR, FT401-PA MX.
The best UHF LaundryChip™ in a 2D-code-integrated version (QR code or Datamatrix), readable with any smartphone! Suitable for work wear and private wear. Discover more.

LaundryChip™ 403 with 2D CODE
FT403 QR, FT403 MX.
The smallest UHF LaundryChip™ in a 2D-code-integrated version (QR code or Datamatrix), readable with any smartphone! Suitable for work wear and private wear. Discover more.

LaundryChip™ 40I MAT
FT40I MAT
The 1st LaundryChip specifically designed to identify mats! Discover more.

TrolleyChip Datamatrix
T-TC860C / T-TC900C.
High-performance RFID transponder for tracking of laundry carts, with rugged design for high durability and laser engraved with datamatrix code.


ORION T-BT 1315 HT 15 mm / 1320 HT 22 mm
HF Transponder, 100% PPS material.
OEKO-TEX® Standard 100 CERTIFIED: discover more.


R-UHF-R700
UHF 4 ports Stationary Reader also available with Cloudburst, a software layer developed specifically by Datamars for the laundry needs: discover more.

R-UHF-SR420 / SR220
UHF Stationary Reader, available with 2 or 4 ports. Readers are also available with Cloudburst, a software layer developed specifically by Datamars for the laundry needs: discover more.

R-DT-UHF-CW-KBW-101 / R-DT-UHF-CW-RS232-101
All-in-one stationary UHF reader with integrated antenna perfect for light industrial usage.


R-HF-LR1002-FG-CBO
HF reader for combo applications, supporting HF/LF or HF/LF/UHF reading systems.

R-IN1300 MID
Stationary reader (2W, serial & USB port).

R-IN1300 MC
Stationary reader, MC with 9x antenna connector.






A-UHF-LNG-201 / A-UHF-MNG-201
UHF hanging conveyor antenna to precisely identify UHF tagged textiles thanks to an homogeneous reading area.

A-UHF-CON-AO-101 / A-UHF-CON-CBO-101
A-UHF-CON-AO-101: UHF Add-On Antenna, shielded vertical Conveyor, (ETSI).
A-UHF-CON-CBO-101: LF-UHF Combo Antenna, shielded vertical Conveyor, (ETSI).
*Not available in USA

A-UHF-TT-AO-101 / A-UHF-LF-TT-CBO-101 / A-UHF-HF-TT-CBO-101
A-UHF-TT-AO-101: UHF Add-On Antenna, TableTop.
A-UHF-LF-TT-CBO-101: LF-UHF Combo Antenna, TableTop.
A-UHF-HF-TT-CBO-101: UHF-HF Combo Antenna, TableTop.

A-UHF-SLIMQ-FF
UHF SlimQ Antenna FF (far field), well suited for UHF reading textile applications like hanging conveyors, belt conveyors and table tops. Available in 2 versions: TILE, without casing, and PANEL, assembled in a plastic case.

A-PO-UHF STICK
UHF handheld antenna perfect for manual readings requiring immediate transmission.








S-UHF-PORTAL-201
The UHF Portal 201 is a heavy duty reading portal designed to read trolleys on the soil side, typically at the truck unloading area of the laundry.
Discover more.


S-UHF-TUNNEL-201
The UHF Open Tunnel 201, powered by artificial intelligence (RFAID™), has been designed to be mounted on any existing laundry conveyor belt and is the perfect reading system to read clean stacks of textiles. Discover more about the use of artificial intelligence in our RFID systems.

CLOSED PORTAL (S-UHF-PORTAL-101-US)
Lightweight and dismountable UHF single door, manually operated cabinet designed to scan carts on both soil and clean side.
WHICH READING SYSTEM BEST MEETS YOUR NEEDS?
See here for a comparison between them.

S-UHF-ARCH-101
UHF arch system perfect for reading textiles on the soil side moving on conveyors.

S-UHF-A-GATE-101
Freestanding gate to monitor textiles as they are taken out of the facility.

S-UHF-SORTICART-101
UHF cart with separate bins for separated collecting garments and linen on the soil side. The system immediately alerts the operator if a linen or garment has been placed in the wrong bin. The cart is battery powered with enough capacity for a full day’s work. Perfect solution for elderly homes & communities.

S-UHF-PORTAL-201
The UHF Portal 201 is a heavy duty reading portal designed to read trolleys on the soil side, typically at the truck unloading area of the laundry.
Discover more.


S-UHF-TUNNEL-201
The UHF Open Tunnel 201, powered by artificial intelligence (RFAID™), has been designed to be mounted on any existing laundry conveyor belt and is the perfect reading system to read clean stacks of textiles. Discover more about the use of artificial intelligence in our RFID systems.

S-UHF-LITECAB-101
Light and dismountable UHF manually operated single door cabinet, suited for space limited applications. Easy & quick to install, Litecab is available in two versions: small and large. Discover more.

S-UHF-CAB-201
4 panels cabin in automatic version for UHF textile trolley scanning.
WHICH READING SYSTEM BEST MEETS YOUR NEEDS?
See here for a comparison between them.


A-UHF-R700-HUB
UHF Antenna HUB to expand the number of antennas that can be connected to an Impinj R700 reader.

A-UHF-SR-HUB
Antenna HUB to expand the number of antennas that can be connected to an Impinj SR420 or SR220 reader.

P-UHF-CBO
Cable that connects an HF or LF reader to a UHF reader to create a combo solution for a smooth RFID technology migration.

P-UHF-R700-LTSR-2C
2-color (green/red) signal LED Stack-Light with built-in buzzer designed to display the status of the UHF reader.

P-UHF-SR-LTSR-3C & P-UHF-SR-LTSR-3C-RS232
3-color (green/yellow/red) signal LED Stack-Light with built-in buzzer designed to display the status of the UHF reader. Available in two versions, with or without serial cable (RS232) for the data transmission.


STORM DEVICE MANAGEMENT
STORM is a web platform that allows to manage efficiently and remotely all your RFID devices installed in multiple locations, preventing downtimes and data losses. Discover more.

CLOUDBURST
Tailored for UHF readers and reading systems, Datamars Cloudburst software has been designed specifically for the laundry environment. Discover more.
IMPORTANT: Cloudburst now requires the reader’s firmware version 7.6.1 on the SR420/220/120 readers or firmware version 8.2.2 on the R700 reader. Please contact us for more information.
See our video tutorial series:
